TDM-pixie

SHDSL (Single-pair High-bit-rate Digital Subscriber Line) Router, provides a broadband transmission with bandwidth up to 5.696Mbps (15Mbps for PAM128) over a single pair of copper wires for LAN connection between two local area networks.
PIXIE(v2) confirms to ITU-T G.991.2, the GSHDSL requirements. 1 / 2 pair of PIXIE(v2) offers a cost effective symmetrical broadband solution for bandwidth-hungry applications such as LAN-to-LAN connection and Internet.

PIXIE-2R

enquiry

4 – 10/100Base T, 1-SHDSL(2W), Managed, Power – AC+DC

Specifications

Interface

4 ports RJ45 for 10/100Mbps Ethernet LAN connection
RJ-45 ports for G.SHDSL connection
1 console port for local configuration and management

ATM Protocol

ATM adaptation layer type 5 (AAL5)
VC multiplexing and LLC encapsulation.
Multi-protocol over AAL5 (RFC 1483 bridged PDU),Support 5 PVCs.

Routing Capability

Support IP/TCP/UDP/ARP/ICMP protocols
IP routing with static routing and RIPv1/RIPv2 (RFC1058/2453).

G.SHDSL Specification

Fully compliant with standards of ETSI (SHDSL, SHDSL.bis) ITU (G.SHDSL, G.SHDSL.bis, g.998.2/g.bond) and IEEE (EFM).
Line Code: TC-PAM 16/32/64/128
M-pair mode for 1/2 pairs
ITU G.991.2 Annex A ,B
STU-C/STU-R mode selectable
Impedance : 135 ohm
SNR /Attenuation Value calculation.

Environment

Operating Temp : 0° to 45°C
Storage Temp : -10° to 70°C

power

AC 90~260Vac(47~63Hz), DC 36 ~ 72 Vdc. AC+DC

Network Management

Web-based GUI for express setup, configuration and management
CLI interface for local console and Telnet access
Password protected management
SNMP management with SNMPv1/v2c/v3
Software upgrade via HTTP

Bridging

IEEE 802.1D transparent learning bridge
Up to 1K MAC learning addresses

Configuration

Local console
Telnet access
Web-based GUI
